Apple files patent for camera lens controlled by 'artificial muscle'

Cheap, low-power polymer deltoids designed to pump up skinnier iPhones, iPads

Beginner's guide to SSL certificates

Apple has filed a patent application for using "artificial muscle" technology to focus cameras in devices such as its iPhone and iPad, a tech that could allow for slimmer mobile shiny-shiny.

Illustration from Apple patent application 'Artificial Muscle Camera Lens Actuator'

Fire up that 'muscle structure' to pull the lens down onto its springy base (click to enlarge)

United States Patent Application No. 20140168799, entitled – appropriately enough – "Artificial Muscle Camera Lens Actuator", describes a method of creating an artificial muscle structure based on electroactive polymers (EAP) that would replace the comparatively bulky voice coil motor (VCM) tech widely used for mobile-camera focus duties.

The application, filed last August and published on Thursday, admits that the idea isn't new. "There have been suggestions to use artificial muscle technology for implementing a camera autofocus lens actuator," it acknowledges.

What has changed, the filing says, is that EAP materials can now be "engineered and developed to for high volume manufacture." According to Apple, there have been attempts to use EAP to create an autofocus lens, "but a completely engineered solution for high volume manufacture or mass production may not be available."

Illustration from Apple patent application 'Artificial Muscle Camera Lens Actuator'

Three tiny woks nestle together to create an electroactive polymer lens actuator (click to enlarge)

Apple's "completely engineered solution" involves EAP fabricated in a "frusto-conical shape" – a truncated cone – surrounded by a negative electrode on top and a positive electrode beneath. This three-layer construction surrounds a matching frusto-conical lens; the entire construction is encased in a metal frame and supported below by pre-tensioned springs.

The "artificial muscle" can be stimulated to position the lens-EAP assembly upward or downwards by changing the electrical potential between the negative and positive electrodes, thus changing the focal length of the lens in relation to the camera's image sensor, which is at the base of the metal frame.

Illustration from Apple patent application 'Artificial Muscle Camera Lens Actuator'

the 'Artificial Muscle Camera Lens Actuator' can both focus and squint (click to enlarge)

In addition to this up-down movement of the lens-EAP assembly, an additional circular electrode-EAP assembly sits on top of the frusto-conical lens, with a central hole that acts as the camera's aperture. When the potential of the electrodes sandwiching this assembly changes, the hole can shrink or expand, thus changing the size of the aperture, which changes the camera's f-stop.

The advantages of this scheme are threefold, the filing notes. First, there's the possibility of what the filing calls a "significant cost reduction" versus using a voice-coil motor to handle focusing. Second, the assembly has the capability of supporting larger optical elements "due to its generally frusto-conical shape." Third, compared with a voice-coil motor scheme, an EAP-based focusing system "may exhibit extremely low power consumption."

It is, of course, impossible to know whether this artificial-muscle focusing scheme will ever make it into an Apple iPhone or iPad – or, for that matter, iWatch or iWhatever. However, if this muscular device can be engineered to work with precision, and if those three goals can be met, we wouldn't bet against it. ®
